Designed for easy access and ultimate cruising comfort, Chatham Rev+ 2 makes every ride feel like a sunny-day stroll. With its low-step frame and relaxed geometry, hopping on and off is simple—perfect for errands, commutes, or just soaking up the coast.
The powerful upgraded Ananda e-system pairs a 500W rear hub motor with a seamlessly integrated 48V/500Wh battery, giving you up to 75 miles of range and the freedom to ride farther with less effort.
Whether you’re getting a boost from one of four pedal assist levels or going full throttle, this electric beach cruiser delivers smooth, confident performance. 3-inch-thick puncture-resistant tires absorb the bumps in your path, while full-coverage fenders protect from splashes when the roads get messy. An integrated headlight and included taillight with brake function keep you visible from dusk to dawn, so every ride ends as comfortably as it began.
Customized Ananda E-System
The handlebar-mounted buttons control everything, including throttle, lights, Pedal Assist, walk mode, and more – right at your fingertips. Keep track of all your riding stats with the upgraded color display screen.
Durable, Long-Lasting, High Range
48V/500Wh Li-ion battery using LG 21700 cells offers a range of up to 75 miles and can be charged on or off the bike. Fully charges within 5-6 hours
Quiet, Consistent Braking
Tektro mechanical disc brakes with 180mm rotors offer more reliable stopping power, so you can brake confidently in all kinds of weather conditions.
Cruise Smoothly
Extra wide and grippy 3” tires roll right over bumps for a smooth ride, with additional puncture protection that keeps the risk of flat tires to a minimum and a versatile Shimano 7-speed Mega-Range drivetrain that makes riding uphill or into headwinds a breeze.
Superior Grip All Around
Sweaty palms and slippery feet have met their match with comfortable, nonslip handlebar grips and pedals.
Stay Seen, Stay Safe
An integrated front light and battery-operated rear light illuminate your path and help keep you safe while riding in low light. The taillight’s automatic brake indicator further improves the bike’s visibility.
Easy-Change Rear Wheel Removal System
retrospec’s proprietary easy-change system allows you to easily remove and replace the rear wheel whenever you need to take a look under the metaphorical hood.
Comfortable Riding
This ebike’s step through frame, swingback handlebars, and Selle Royal Gel padded saddle promote a comfortable and relaxed upright riding position, and full-wrap fenders protect you from the elements, keeping you safe and dry on your journey.
Customize to Meet Your Needs
With mounting points to easily add a rear rack, basket, fenders, and more, you can redesign your ride to be tailored to your adventures.
Specifications
FRAMESET
Sizes - 16" Step Through
Material - Alloy
Dropouts - 1x rear fender eyelets, rear rack mounts,
Replaceable Der Hanger Yes
Fork - Rigid Steel
WHEELSET
Rims - Alloy 36H for disc brake
Hubs - Alloy bolt on 17mm nut
Spokes - 13G w/brass nipples
Tires - 26x3.0 with Puncture Protection
E-POWER SYSTEM
Motor - 48V/500W Geared
Drive - Mode PAS/Thumb Throttle Left Side, Cadence Sensor
Display - Full Color Center Mounted TFT
Charge Time (empty to full) - Approximately 5-6hrs hrs.
Range - 75 miles
Battery - 500Wh/48VLG 21700 cells; Charge on or off bike
UL Testing - UL2849 & UL2271 Certified
Pedal Assist - 1-4 PAS, Throttle and Walk-Mode
DRIVETRAIN
Derailleur - Rear Shimano Tourney 7 speed
Shifter(s) - Shimano Tourney 7 speed
Crankset - 3-Piece Aluminum
Chain - KMC 7 Speed
BB - Sealed Catridge
Freewheel/Cog - Shimano 7 Speed 14-34T
COMPONENTS
Headset - 1-1/8" Semi-Integrated Threaded
Brakes - 5 Star Lever; Tektro Mechanical Caliper w/ Tektro Anti-Vibration 180mm Rotors and Semi-Metallic Pads
Handlebars - Alloy Cruiser
Grips - Lock-On Comfort
Stem - Die-Cast Alloy. 25.4mm Clamp
Saddle - Selle Royal Gel Saddle
Seatpost - Aluminum 30.9mm Diameter, 350mm Length
Seatpost Clamp - Alloy QR
Pedals - PP Platform w/ Non-Slip Tread
EXTRAS
Kickstand - Aluminum Chainstay Mounted, 40mm Bolt Pattern
Headlight - Integrated Front 80 Lux 12V
Rear Light - Fender Mounted Tail Light with Integrated Reflector and Brake Light Function
Chaincover - Full Coverage
Tools - 2/3/4/5/6mm hex wrench; 8/10/15/17mm open wrench; 13g spoke wrench
Recommended Weight Limit 350lbs
